up to 2000kg/hr, particle size down to 30μm
highly polished 316 stainless steel (finish Ra <- 0.8u) with Hastelloy C22 feed hopper bottom cone
(24) pharma execution fixed knives/hammers, rotor speed 1000 - 6000 rpm,
ATEX 1D milling chamber, rest of mill is ATEX 2D,
temperature sensors, sampling device, level sensor, pressure sensor, Oxygen sensor,
auxiliary equipment includes:
cleaning rig, Pneumatic vacuum conveyor, feed hopper, feeding device, de-dusting filter type ProFi-clean 90, de-dusting filter type ProFi-clean 250, butterfly valves, Bag holding device, Mettler Toledo scales,
Type: Pulverizer
Subtype: Hammer
Manufacturer: Kek
Condition: Used
Material: Stainless Steel 316
Inlet Diameter: 559 mm (22 in)
Motor Power (Design): 5.4 kW (7.3 HP)
Beta grinde mill Bowl 22" diameter x 14" straight side with discharge chute. with pneumatic hammer to dislodge product from agitator.
Orientation: Vertical.
Type: Pulverizer
Subtype: Hammer
Manufacturer: Fitzpatrick
Model: D6
Condition: Used
Material: Stainless Steel 316
Inlet Diameter: 304.8 mm (12 in)
Motor Power (Design): 11.2 kW (15 HP)
w/screw feed Unit has 12" x 12" hopper w/feed screw Screw driven by 3/4 HP, US varidrive 3/60/230/460 volt. UL label
Orientation: Horizontal.
