Glasslined Tank - IPP# 213113

Type: Tank

Manufacturer: Ceramic Coatings

Model: Reciever

Condition: Used

Material: Glasslined

Capacity (Design): 757 L (200 gallons)

Orientation: Vertical

• One 8" man way with sight glass pad
• Heads are 0.559"

Diameter: 1,050 mm (42 in). Straight-side Length: 660 mm (26 in). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 232.2 °C (450 °F). Jacket Type: Standard. Jacket Material: Carbon Steel. Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Vacuum: Yes. Support: Lugs.

Type: Tank

Manufacturer: DeDietrich

Model: HT 1500

Condition: Used

Material: Glasslined

Capacity (Design): 5,700 L (1,500 gallons)

Orientation: Horizontal

Diameter: 1,800 mm (70 in). Straight-side Length: 2,000 mm (78 in). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 200 °C (392 °F). Vacuum: Yes. Support: Saddle.

Type: Tank

Manufacturer: Pfaudler

Condition: Used

Material: Glasslined

Capacity (Design): 9,450 L (2,500 gallons)

Orientation: Horizontal

Diameter: 2,150 mm (85 in). Straight-side Length: 2,150 mm (84 in). Support: Legs.

Type: Tank

Manufacturer: Pfaudler

Condition: Used

Material: Glasslined

Capacity (Design): 1,900 L (500 gallons)

Orientation: Vertical

Diameter: 1,400 mm (56 in). Straight-side Length: 1,150 mm (46 in). Internal Pressure: 5.2 bar (75 psi). Internal Temperature: 176.7 °C (350 °F). Support: Legs.
